AES ELPRO S20 Control Unit - 7278L
Details
AES ELPRO S20 Control Unit - 7278L
The AES ELPRO S20 Control Unit is designed to operate up to two hydraulic or semi-automatic bollards using preprogrammed logic and safety monitoring. It includes inputs for magnetic limit switches, flashing lights, heaters, and safety accessories. The unit supports step-by-step and pedestrian open modes and is equipped with the Intelligent Safety Check (I.S.C.) system to provide real-time diagnostics. It integrates with 3-lamp traffic lights, external open/close commands, and Elpro beepers for audible operation confirmation. Housed in an IP55-rated enclosure, the S20 is an ideal solution for compact traffic control setups or isolated bollards.
Specifications
- Max bollards: 2
- Power supply: 230V 10%, 50Hz
- Operating temperature: -40 Degrees C to 80 Degrees C
- Enclosure: IP55-rated polycarbonate box
- Safety system: I.S.C. diagnostic self-test
Features
- Controls two automatic or semi-automatic bollards
- Step-by-step and pedestrian function modes
- Built-in LED status indicators and fuse protection
- Compatible with beepers, traffic lights, and heater kits
- Ideal for private driveways, isolated entries, or small facilities
SKU | 7278L |
---|---|
Product Type | Bollard Control Unit |
Manufacturer | AES Global, LLC |
Installation Guide | Download PDF file |
