AWID OSDP Switchplate Type UHF Reader (36" Range) - XN-300-0-0

The AWID OSDP Switchplate Type UHF Reader delivers short-range access for both vehicles and pedestrians by reading UHF credentials in a single compact switchplate design. It installs on a standard wall box or mullion and supports familiar output formats for modern access systems. Communication options include Wiegand, RS-232 and OSDP with encrypted data channels for enhanced control-level security. With read ranges up to three feet, it accommodates mixed-use access points such as parking gates or interior doors. Audible beeper and LED feedback confirm each read, and the ABS enclosure is sealed for protection in varied environments.

Features

• Single-gang switchplate reader capable of reading the same UHF credential for both drivers and walkers.
• Selectable interface supports Wiegand, RS-232 or OSDP protocols to adapt to legacy or high-security systems.
• Read distance of up to 3 feet on wall or metal surfaces when installed with the correct credential type.
• Frequency-hopping UHF operating in the 902-928 MHz band to ensure reliable read performance in RF noisy areas.
• Includes visual LED indicator and beeper to provide immediate confirmation of credential presentation.

Specifications

• Reading Distance: Up to 3 feet when mounted on a wall or metal surface.
• Frequency Band: 902-928 MHz with frequency-hopping technology for RF performance.
• Power Supply: +5 to +12 VDC regulated, minimum current rating of 1 ampere.
• Communication Protocols: Selectable Wiegand, RS-232 or OSDP with high-security encryption support.
• Code Formats: Supports credential formats from 26-bit through 50-bit.
• Wiring (Wiegand Interface): 22-gauge stranded 4-conductor overall shielded cable with lengths up to 500 feet permissible.
• Dimensions: 3.25 in (W) x 3.625 in (H) x 1.0625 in (D).
• Weight: Approx. 6.2 oz (175 g).
• Material/Finish: ABS one-part sealed enclosure, black in colour.
• Integrated Cable: 18-inch, 10-conductor overall shielded, grey jacket.
• Mounting Style: Wall or mullion; two-screw mount on single-gang utility box or flat surface.
• Operating Temperature: -31 Degrees F to +150 Degrees F for 50 % duty cycle; -31 Degrees F to +115 Degrees F for 100 % duty cycle.
• Operating Humidity: 0% to 95% non-condensing.
• Certifications: ISO 9001:2000, FCC Part 15, Industry Canada (IC), RoHS compliant.
