Details

BEA 1-5/8" Delayed Action Jamb "Push to Exit" Button (Text Only, Red) - 10ACPBDA3

With a narrow-profile design and vivid red color, the BEA 1-5/8" Delayed Action Jamb "Push to Exit" Button (Text Only, Red) features a green “Push to Exit” button. With pneumatic timing, this button allows for adjustable delayed closures. Designed with a durable steel faceplate, the BEA 1-5/8" Delayed Action Jamb "Push to Exit" Button (Text Only, Red) is perfect for controlled-exit applications needing a low-profile interface.

Features:

• 1-5/8" red push button with "Push to Exit" text for clear and immediate door release identification
• Adjustable pneumatic delayed action timer provides a delay range of 2 to 60 seconds
• Jamb-style stainless steel faceplate designed for tight frame mounting needs
• Self-contained pneumatic timer requires no external power or wiring

Specifications:

• Life Cycle: Over 1,000,000 mechanical operations
• Activation Type: Pneumatic delayed action
• Button Diameter: 1-5/8"
• Faceplate Dimensions: 1.75" x 4.5" (jamb configuration)
• Switch Rating: 5 A @ 125 VAC or 2.5 A @ 12-24 V AC/DC
• Time Delay: Adjustable from 2 to 60 seconds ~15%
