BEA Touchless Magic Wave to Open Actuator Jamb Plate (Accessibility Logo Only, Stainless Steel) - 10MS41-JPAL

Key Features:

• Touchless BEA MAGIC Switch actuator designed for hygienic, contact-free activation of automatic doors
• Constructed with a stainless steel jamb plate featuring the accessibility logo only, ideal for ADA-compliant facilities
• Uses microwave Doppler radar technology to detect motion for reliable activation without physical contact
• Adjustable detection range from 4 to 24 inches accommodates varying installation needs and user approaches
• Relay output hold time is configurable from 0.5 to 30 seconds for flexible door operation timing
• LED illumination and optional audible feedback enhance user interaction and visibility in low-light environments
• Rated IP55 for dust and moisture resistance, with optional sealing to achieve IP65 for outdoor or harsh environments

Specifications:

• Technology: Microwave Doppler radar sensor
• Detection Range: Adjustable between 4 and 24 inches
• Frequency: 24.125 GHz, radiated power under 5 mW/cm sq
• Power Supply: 12 to 24 VAC ~10% or 12 to 24 VDC +30%/-10%
• Relay Output: Form C relay, rated 1 A at 125 VAC or 60 VDC
• Output Hold Time: Adjustable from 0.5 to 30 seconds
• Power Consumption: Under 1.5 W
• Operating Temperature: -4 F to 131 F (-20 C to +55 C)
• Enclosure Rating: IP55 (upgradable to IP65)
• Faceplate Dimensions: 1.75 inches wide x 4.5 inches high x approximately 1 1/8 inches deep
• Faceplate Material: Stainless steel jamb plate with accessibility logo only
