BEA 11-Pin DIN Rail Matrix Socket without Wire Tyco (MT 78 760) - 70-0262

Key Features:

• Socket base designed for Matrix Family induction loop detectors using an 11-pin connector
• DIN-rail mountable design for streamlined installation in door operator or traffic-control cabinets
• Screw-terminal wiring simplifies loop detector replacement and minimizes downtime
• Compact footprint for efficient panel layout and installation flexibility
• Rated for use with BEA single- and dual-loop detector modules in industrial gate and door applications

Specifications:

• Connector Type: 11-pin male (86CP11) socket
• Mounting Style: DIN-rail mount
• Compatible Modules: BEA Matrix Family single and dual loop detectors
• Operating Temperature Range: -22 F to +158 F (-30 C to +70 C)
• Degree of Protection: IP40
• Weight: Approximately 7 oz
• Dimensions: Approx. 1.5 in (W) x 3 in (H) x 3 in (D)
