BEA Double Microcell Beam with Adapters (Replaces Optex Beam) - 10MICRO1DADAPT

Key Features:

• Adapter kit allowing Microcell double-beam set to replace Optex style safety beams without rerunning cable runs
• Includes two pairs of emitter/receiver heads and adapter modules to interface with existing wiring layout
• Fits smoothly into 1/2 in pre-drilled holes and uses a single wire connection per side for ease of installation
• User-friendly alignment indicators and supports both sliding and swinging door threshold or guide-rail applications
• Rated for rugged indoor or outdoor environments to deliver consistent presence detection in bright or harsh conditions

Specifications:

• Technology: Active Infrared
• Detection Mode: Presence (Beam Interruption)
• Minimum Mounting Height: 12 in from floor
• Minimum Distance Between Beams (when crossed): 12 in
• Range of Detection: 3 ft to 15 ft (minimum to maximum)
• Alignment Tolerance: 8 Degrees
• Response Time: ~ 40 ms
• Hold Time: 300 ms
• Supply Voltage: 12-24 VAC ~10 Percent / 12-24 VDC -5 Percent / +30 Percent
• Current Consumption:< 100 mA
• Output Contact Rating: 1 Relay (NC / NO Contacts)
• Max Contact Voltage: 50 VAC/VDC
• Max Contact Current: 1 A
• Max Switching Power: 30 W (DC) / 60 VA (AC)
• Operating Temperature Range: -30 F to +131 F
• Degree of Protection: NEMA 4 / IP65 (beam heads)
