BEA 6" Round MS31 Magic Wave to Open Actuator Faceplate (Accessibility Logo Only, Gray) - 70-5853

Key Features:

• 6-inch round actuator faceplate designed for BEA MS31 Magic "Wave to Open" touchless activation systems
• Gray finish featuring only the accessibility logo for a ADA-compliant design suited for modern entryways
• Pairs with BEA MS31 sensor modules utilizing microwave Doppler radar for hands-free door activation
• Adjustable LED illumination options and detection field settings available when integrated with the MS31 actuator
• Constructed for simple mounting on 6-inch round boxes, ensuring precise alignment and secure installation

Specifications:

• Technology: Microwave Doppler Radar (when paired with MS31 actuator)
• Detection Range: Adjustable from 4" to 24"
• Output: Relay with switch-over contact rated up to 60 VDC or 125 VAC at 1 amp resistive (with actuator)
• Supply Voltage: 12 to 24 VAC ~10 percent or 12 to 24 VDC +30 / -10 percent (with actuator)
• Power Consumption: Less than 1.5 watts (with actuator)
• Mounting Option: 6-inch round faceplate, 1/4" thick, compatible with standard round mounting boxes
• Material: Polycarbonate and polyethylene faceplate construction
• Protection Rating: IP54 when assembled with MS31 sensor, suitable for indoor or semi-protected outdoor use
• Operating Temperature Range: -4 F to +131 F (-20 C to +55 C)
