Details

BEA 6" Round MS31 Magic Wave to Open Actuator Faceplate (Accessibility Logo Only, White) - 70-5856

Key Features:

• 6-inch round actuator faceplate compatible with BEA MS31 Magic "Wave to Open" touchless activation systems
• White finish featuring only the accessibility logo for a professional, and ADA-compliant look
• Pairs with BEA MS31 sensor modules that use microwave Doppler radar for hygienic, hands-free operation
• Supports adjustable detection range and LED indicator options when connected to the full MS31 actuator assembly
• Designed for a precise fit with 6-inch round surface or flush mount boxes to ensure a stable and polished installation

Specifications:

• Technology: Microwave Doppler Radar (requires MS31 actuator)
• Detection Range: Adjustable between 4" and 24"
• Output: Relay with switch-over contact rated up to 60 VDC or 125 VAC at 1 amp resistive (with actuator)
• Supply Voltage: 12 to 24 VAC ~10 percent or 12 to 24 VDC +30 / -10 percent (with actuator)
• Power Consumption: Less than 1.5 watts (with actuator)
• Mounting Option: 6-inch round faceplate, 1/4" thick, compatible with standard 6-inch mounting boxes
• Material: Polycarbonate and polyethylene faceplate construction
• Protection Rating: IP54 when assembled with MS31 sensor, suitable for indoor or semi-protected outdoor use
• Operating Temperature Range: -4 F to +131 F (-20 C to +55 C)
