Details

BEA MS31 Magic "Wave to Open" Double Gang Actuator Faceplate (White) - 70-5846

Key Features:

• Touch-free actuator designed for double-gang faceplate use and triggered by a "wave to open" gesture for barrier-free access
• The detection zone can be set anywhere from 4" to 24" to match various approach distances and user movement
• Dip-switch settings allow configuring the LED indicator to either stay on during detection or only light after activation
• Selectable toggle or timer mode lets the device either activate once per wave or hold open for 0.5 to 30 seconds to accommodate different use-cases

Specifications:

• Technology: Microwave Doppler Radar operating at 24.125 GHz
• Detection Mode: Bidirectional motion sensing with an adjustable range from 4" to 24"
• Output: Relay with switch-over contact rated for up to 60 VDC or 125 VAC at 1 amp resistive
• Supply Voltage: 12 to 24 VAC ~10 percent or 12 to 24 VDC +30 / -10 percent
• Power Consumption: Less than 1.5 watts
• Mounting Option: Double-gang faceplate with dimensions of 4 1/2" x 4 1/2" x 1/4" thick
• Material: Polycarbonate and polyethylene construction
• Protection Rating: IP54 for use in indoor or semi-protected outdoor environments
• Operating Temperature Range: -4 F to +131 F (-20 C to +55 C)
