BEA Phoenix EX Motion Sensor with Tamper Alert & 100ft Harness Standard Mounting Height - 10PHOENIXEX-IT100

Key Features:

• Industrial-grade microwave motion sensor engineered for automatic door activation and safety in demanding areas
• Includes an integrated tamper alert system that detects unauthorized interference or removal of the sensor housing
• Equipped with a 100-foot harness to support extended installation distances at standard mounting heights
• Utilizes unidirectional radar technology to accurately detect approaching motion while ignoring cross-traffic
• Optimized digital signal processing ensures consistent performance and reduces false activations
• Built with a sealed, weather-resistant enclosure suitable for both indoor and outdoor mounting

Specifications:

• Technology: Microwave Doppler radar for motion detection
• Mounting Height: Up to 13 feet standard installation height
• Detection Range: Adjustable between 2 and 20 feet
• Power Supply: 12 to 24 VAC ~10% or 12 to 24 VDC ~30%
• Output: SPDT relay, rated up to 1 A at 30 V (resistive load)
• Operating Frequency: 24.150 GHz nominal (K-band)
• Tamper Alert: Built-in circuit output for external alarm connection
• Response Time: 200 milliseconds typical
• Operating Temperature: -4 F to 131 F (-20 C to +55 C)
• Protection Rating: IP54 when properly sealed
• Harness Length: 100 feet, prewired and shielded for signal stability
• Dimensions: 5.12" x 3.15" x 4.33"
