BEA 12-24VDC Power Supply & Battery Charger (UL Rated) - 10PS12-24

Key Features:

• Selectable 12 VDC or 24 VDC output to support a wide range of access-control and safety devices
• Built-in battery charger and standby capability for uninterrupted operation during AC power loss
• UL/ULC listed for use in access control and life-safety systems, ensuring compliance and reliability
• Compact wall-mount metal enclosure with knockouts and pre-punched holes for easy installation
• Overload, short-circuit and thermal protection included to safeguard connected equipment

Specifications:

• Input Voltage: 115 VAC, 60 Hz, - Current: Approx. 0.6 A
• Output Voltage: 12 VDC or 24 VDC (field-selectable)
• Output Current: 1.75 A continuous maximum
• Battery Backup Support: Yes (with optional batteries) - automatic switchover when AC fails
• Compatibility: Works with BEA's access control components including push buttons, safety sensors, electric strikes and maglocks
• Compliance: UL294, ULC listed for access control/signal equipment
• Operating Temperature Range: -4 F to +158 F (-20 C to +70 C)
