BEA MS31 Standard Magic "Wave to Open" Actuator 6" Round Plate (Text & Hand Logo, White) - 10MS31R-W

The BEA MS31 Standard Magic "Wave to Open" Actuator uses microwave technology that can automatically open doors once motion is detected. These door actuators are ideal for shopping centers, hospitals, commercial complexes, or any facility that may benefit from enhanced accessibility or reduced touchpoints at entrances. The MS31 includes adjustable LED settings and silent activation, making it a great solution for environments that require sensitivity to noise. The configurable detection zone allows the user to adjust the sensitivity of the actuator in a way that will best suit the needs of the location. The 10MS31R-W version is made with a white faceplate that includes "WAVE TO OPEN" text and an icon of a waving hand.

Specifications:

• Faceplate Dimensions: 6" x 0.25"
• Faceplate Color: White
• Detection Technology: Microwave doppler radar
• Detection Range (adjustable): 4 to 24"
• Power Supply: 12 to 24 V AC ~10% or 12 to 24 V DC +30%/-10%
• Power Consumption: <1.5 W
• Output Relay Rating: Form C relay, 1 A max at 125 V AC / 60 V DC
• Output Hold Time: 0.5 to 20 seconds
• Temperature Range: -4 degrees F to 131 degrees F (-20 degrees C to +55 degrees C)
• Enclosure Rating: IP54
• Compliance: FCC and Industry Canada certified
