BEA Standard Magic "Wave to Open" Actuator Jamb Plate (Text & Logo, White) - 10MS31J-W

Key Features:

• Touchless microwave-activated actuator designed for hygienic and contact-free door activation
• White jamb-style faceplate with clear "Wave to Open" text and accessibility logo for enhanced ADA compliance
• Microwave Doppler radar detection technology ensures reliable motion sensing through various materials
• Adjustable detection zone ranging from 4 to 24" for versatile application in different areas
• Selectable toggle and momentary relay modes allow tailored activation timing for automatic doors
• Compact form factor ideal for jamb or narrow installations where space is limited

Specifications:

• Detection Technology: Microwave Doppler radar motion sensing
• Detection Range (adjustable): 4 to 24"
• Power Supply: 12 to 24 VAC ~10% or 12 to 24 VDC +30%/-10%
• Output Relay Rating: Form C relay, 1 A max at 125 VAC / 60 VDC
• Power Consumption: Less than 1.5 W
• Operating Temperature: -4 F to 131 F (-20 C to +55 C)
• Enclosure Rating: IP54, suitable for indoor areas
• Faceplate Dimensions (Jamb Style): 4.5 in (H) x 1.75 in (W) x 0.25 in (T)
• Faceplate Color: White with "Wave to Open" text and accessibility logo
• Certifications: FCC and Industry Canada compliant
