BEA Standard Magic "Wave to Open" Actuator Single & Double Gang Plate Kit (Text & Logo, White) - 10MS31U-W

Key Features:

• Touchless microwave actuator for hygienic and convenient door activation without physical contact
• Includes both single-gang and double-gang white faceplates with "Wave to Open" text and accessibility logo for universal mounting options
• Microwave Doppler radar sensing technology detects motion from 4 to 24" with adjustable range for precise control
• Selectable operation modes (momentary or toggle) for compatibility with a wide range of automatic door systems
• IP54-rated construction provides protection against dust and moisture for dependable use in commercial and healthcare areas
• Ideal for sanitary, high-traffic, and ADA-compliant entryways requiring contactless activation

Specifications:

• Technology: Microwave Doppler radar motion detection
• Detection Range: Adjustable between 4 and 24"
• Power Supply: 12 to 24 VAC ~10% or 12 to 24 VDC +30%/-10%
• Relay Output: Form C relay rated 1 A at 125 VAC / 60 VDC
• Power Consumption: Under 1.5 W
• Operating Temperature: -4 F to 131 F (-20 C to +55 C)
• Enclosure Rating: IP54
• Included Faceplates: Single-gang and double-gang white faceplates
• Faceplate Color: White with "Wave to Open" text and accessibility logo
• Certifications: FCC and Industry Canada compliant
