Miller Edge MC22 Non-Monitored XR-5 Yellow Chemical Resistant Electric Edge

Details

Miller Edge MC22 Non-Monitored XR-5 Yellow Chemical Resistant Electric Edge

The Miller Edge MC22 Non-Monitored XR-5 Yellow Electric Edge provides dependable contact-sensitive signaling in a simplified configuration. Designed for use on commercial and industrial sectional or rolling doors, this version omits monitored circuitry, making it ideal for less complex access systems. The XR-5 yellow jacket resists chemical exposure and offers excellent visibility for added safety. Custom-made to the exact dimensions and outlet location required, it installs easily into standard bottom retainers.

The edge uses a sealed, flexible PVC structure to conform to floor irregularities, enhancing the seal and reliability of contact detection. The contact mechanism features Miller Edge's Alumaglas technology for responsive signal transmission. The unit is UL 325 recognized and includes a one-year manufacturer warranty.

Key Features

• Non-monitored version for simplified installations
• Bright XR-5 yellow cover for chemical resistance and visibility
• Flexible body adapts to uneven flooring
• Easy to install and available in custom lengths
• UL 325 Recognized Component

Includes

• MC22 Non-Monitored XR-5 Yellow Sensing Edge (cut to size)
• 2 ft. SJTO lead wire, 18-gauge
• 5" trim-to-fit end flaps

Specifications

• Color: Yellow (XR-5 chemical-resistant jacket)
• Length: Custom (in 1/4 in. increments, 1/4 in. tolerance)
• Sensitivity: 3 - 5 lbf (nominal)
• Voltage: Max 24V AC/DC, 1/2 amp
• Electrical Configuration: Normally open (non-monitored)
• Contact Element: Alumaglas
• Material: Reinforced PVC exterior
• Mounting: Fits door bottom bar using mounting channel
• Operating Temperature: UL compliant
• Agency Approval: UL 325
