Miller Edge RBand Monitored Sensing Edge Wireless Gate Transmitter - RB-TX10

Details

Miller Edge RBand Monitored Sensing Edge Wireless Gate Transmitter - RB-TX10

The Miller Edge RBand RX Transmitter, part of the RB-G-K10 RBand Kit, is built for automated gate systems and provides a wireless solution to any hardwired Miller Edge 10K Sensing Edge. Along with the Miller Edge RB-G-RX10 Receiver, The RB-TX10 Transmits a wireless monitored signal to the gate operator controls eliminating the need for any hardwiring. Up to 6 transmitters can be paired with a single RB-TX10 RBand Receiver on 2 separate channels.

Includes:

• (2) 3.6V AA lithium batteries*
• (4) #6 pan head transmitter mounting screws

Required:

• Miller Edge RBand Monitored Wireless Gate Receiver - RB-G-RX10
• Miller Edge 10K (T2/blue band) Sensing Edge

Technical Specifications:

• Dimensions: 1.80" L x 4.78" W x 1.75" H
• Weight: 4.5 oz
• Enclosure Material: Polycarbonate
• Rating: NEMA4
• Power Source: 2 AA, 3.6 V Lithium
• Battery Life: 2-year expectancy
• Input: 10K monitored edge
• Operating Temperature: -40 deg F to 140 deg F
• Frequency: 916 MHz
• Operating Range: 50' nominal; 100' optimal conditions
