BEA MS51 Relay Wave to Open Jamb Actuator (Logo Only) - 10MS51-J

Key Features:

• Compact jamb-mounted actuator designed for hands-free door activation using touchless infrared technology
• Features the BEA logo only for a professional appearance suitable for commercial and industrial facilities
• Active infrared sensing detects intentional motion within a user-adjustable range of 6 to 12"
• Touchless activation enhances hygiene and reduces the spread of contaminants in shared spaces
• Selectable immunity settings help prevent unwanted activations caused by light, reflections, or moisture
• Battery-powered system supports up to three years of reliable performance on standard AA batteries
• Jamb-size faceplate makes it ideal for narrow or limited-mounting spaces, simplifying retrofit installations

Specifications:

• Technology: Dual active infrared motion detection
• Detection Range: Adjustable between 6 and 12"
• Power Supply: 3 VDC (two AA batteries)
• Output: Single galvanically isolated relay output, rated up to 42 VAC/VDC and 100 mA switching capacity
• Operating Temperature: -22 F to 158 F (-30 C to 70 C)
• Enclosure Rating: IP65 for dust and moisture protection
• Faceplate Dimensions: 1.75" x 4.5" x 1.25" (jamb size)
• Material: 304 stainless steel faceplate with BEA logo only and polycarbonate sensor enclosure
