BEA MS51 Relay Wave to Open Single Gang Actuator (Logo Only) - 10MS51-S

Key Features:

• Touchless single gang actuator designed with an accessibility logo only for ADA-compliant door activation
• Employs BEA's active infrared motion sensing technology for dependable, hygienic hands-free operation
• Adjustable detection zone from 6 to 12" to suit different doorway or areaal conditions
• Single relay output compatible with most automatic door operators and access control systems
• Battery-powered for easy, wire-free installation and long operational life
• Single gang stainless steel faceplate provides a compact profile ideal for tight spaces and wall-mounted use
• Sealed sensor enclosure protects against dust, water, and areaal contaminants for consistent performance

Specifications:

• Technology: Active infrared motion sensing
• Detection Range: Adjustable from 6 to 12"
• Power Supply: 3 VDC (two AA batteries)
• Output: Single galvanically isolated relay rated 42 VAC/VDC at 100 mA max
• Operating Temperature: -22 F to 158 F (-30 C to 70 C)
• Enclosure Rating: IP65-rated for protection against moisture and dust
• Faceplate Dimensions: Single gang (4.5" x 2.75" x 1.25" depth)
• Material: 304 stainless steel faceplate with accessibility logo and polycarbonate sensor lens
