Loop Sizes For Your Residential Driveway

Driveway Width		Loop Size		Direct Burial Part Number			Saw-Cut Part Number
9 ft		4x5 or 3x6		RL 18-40 EL 18-60			SC 18-20 SC 18-50
10 ft		4x6 or 3x7		RL 20-40 EL 20-60			SC 20-20 SC 20-50
12 ft		4x8		RL 24-40 EL 24-60 EL 24-100			SC 24-20 SC 24-50 SC 24-100
14 ft		4x10		EL 28-60 EL 28-100			SC 28-50 SC 28-100
16 ft		4x12		RL 32-40 EL 32-60 EL 32-100			SC 32-20 SC 32-50 SC 32-100
18 ft		4x14		RL 36-40 EL 36-60 EL 36-100			SC 36-20 SC 36-50 SC 36-100
20 ft		4x16		EL 40-60 EL 40-100			SC 40-50 SC 40-100

loops
